A 24-meter High Stacker Crane Project for a Food Company in Henan Under Intense Construction

Recently, the beam-type warehouse project undertaken by Tianjin Master is being installed! With advanced technology and rich experience, Tianjin Master has created a scientific plan for this project. Once completed, it will inject strong power into the storage and logistics transportation for this food company.

Project Background

• Solution Type: Beam-type Warehouse

• Cargo Specifications: 1200*1000*1700 (including pallet height)

• Equipment Matching: Equipped with 7 stacker cranes

• Number of Storage Positions: 28,494

Project Planning

At the initial stage of constructing the beam-type warehouse, the design team developed a detailed plan considering various factors such as the space dimensions provided by the site, cargo specifications, and future operational needs. Because food storage has special requirements regarding the environment and space utilization, the design plan not only had to maximize the use of the 24-meter space on the project site but also ensure that each storage position allows for easy access and meets safety standards such as fire safety and ventilation.

Project Construction

Foundation construction is a key step in the beam-type warehouse setup. To ensure the quality and safety of the warehouse, strict material standards were adhered to. For key components like columns and beams, high-quality, high-strength steel was selected, which underwent strict quality testing. These materials have excellent compressive and bending performance, ensuring that the ground can support the weight of the entire warehouse and stored goods.

Safety Assurance

Throughout the entire beam-type warehouse construction process, quality testing and safety assurance have been ongoing. After each construction phase is completed, professional quality inspectors are assigned to perform checks and acceptance tests.

With the project progressing steadily, this beam-type warehouse will soon provide vital support for the efficient and safe storage and operations of the food company.

Integration of Knowledge and Practice Driving Long-Term Success

Tianjin Master is firmly focused on the logistics equipment industry. While establishing a strong presence in the domestic market, it is also committed to executing an international expansion strategy, focusing on research and development, and creating high-quality products to showcase the power of Chinese intelligent manufacturing in broader markets.
